Weight reduction
The ST185 is the heaviest GT-Four made - my Carlos Sainz weighs in at 1450 kg according to the chassis paperwork. Weight kills
performance, hence I decided to take unnecessary weight out of my car. Below you find a list of parts and their weight. I'm not saying
you can just remove these parts for better performance, but it might help you better understand your car's weight (distribution).
Interior |
|
Part |
Weight (kg) |
Remarks |
Carpet, boot |
0.880 |
|
Cup holder |
0.220 |
|
Panel, boot - left |
1.335 |
Including interior light unit, excluding strut cover |
Panel, boot - rear |
0.935 |
|
Panel, boot - right |
1.215 |
Excluding jack compartment panel and strut cover |
Panel, jack compartment |
0.145 |
|
Parcel shelf |
2.980 |
|
Seatbelts, rear |
2.120 |
|
Seat brackets, rear |
0.860 |
5 pc. |
Seats, rear |
16.100 |
Leather, excluding brackets |
Spare wheel |
11.XXX |
Space saver, steel |
Spare wheel clamp |
0.120 |
2 pc. |
Spare wheel cover |
0.705 |
Excluding jack handle |
Steering wheel |
2.185 |
|
Strut covers, rear |
0.110 |
|
|
Engine bay |
|
Part |
Weight (kg) |
Remarks |
Air box |
1.180 |
Including air filter |
Air box feed |
0.190 |
Engine bay side only |
Alternator scoop |
0.310 |
|
Alternator snorkel |
0.750 |
Including brackets |
Battery lead (loom) |
0.195 |
Negative terminal |
Battery lead (loom) |
0.245 |
Positive terminal |
Battery clamp |
0.245 |
2 pc. |
Charcoal canister |
1.360 |
Including brackets |
Coolant pipe, turbo |
0.340 |
Part of stock radiator setup, CS/GrpA Rallye/RC only |
EGR piping |
0.780 |
Piping and valves |
Intake piping |
0.995 |
Air box to turbo |
