Part number |
Part |
Size (mm*) |
Remarks |
SCH80 |
Straight coupler |
80.0 |
Airflow meter (AFM) to straight intake |
SHL12.7 |
Straight hose |
13.0 |
Positive crankcase ventilation (PCV) to oil catch tank, straight intake to catch tank and Idle speed control (ISC) valve |
SR80-70 |
Straight reducer |
80.0 > 70.0 |
Straight intake to turbo |
STP51 |
T-hose |
51.0 |
Turbo to intercooler + blow-off valve |
TCS169/C |
Coolant set |
32.0 |
ST185 specific coolant set, 3 pc. |
VT4B-2W/3m |
Vacuum line |
4.0 |
Vacuum to blow-off valve and boost controller solenoid, intercooler overflow |
VT6.3B-2.5W/3m |
Vacuum line |
6.3 |
Radiator overflow, boost controller solenoid to turbo |
VT8B-3W/3m |
Vacuum line |
8.0 |
Inlet manifold to HKS idle stabiliser |
