Welcome to the Turbocelica.nl ST185 JDM performance parts database. Below you find the ST185 specific JDM parts I've found so far. Some of them are listed as ST205 or SW20 parts but fit the ST185 as well. Engine related parts are all for the 2nd generation 3S-GTE. If a part is discontinued, please let me know so I can keep this page up-to-date. Thanks :)

Brakes
Chassis
Engine
Exterior
Interior
Transmission




Brakes


Big brake kit

Brand Part number Part Remarks
Brash Boy Unknown Big brake kit, front ENDLESS based, 4 pot
C-ONE Unknown ST205 brake kit for ST185, front/rear 16" wheels or bigger, via C-ONE Pro shop
Pit Road M Unknown Big brake kit, front, Type-R AP Racing based, 4 pot, 315 mm two piece discs, 16"
Pit Road M Unknown Big brake kit, front, Type-R Outlaw based, 4 pot, 300 mm two piece discs, 16" req.

Brake discs

Brand Part number Part Remarks
C-ONE FR4351-STB18 Slit brake rotor, front Facelift/CS/GrpA Rallye/RC, slotted
C-ONE FR4243-STB18 Slit brake rotor, rear Facelift/CS/GrpA Rallye/RC, slotted
DIXCEL 311 2711 HD Brake discs, front Pre facelift, heat treated
DIXCEL 311 2711 HS Brake discs, front Pre facelift, heat treated, slotted
DIXCEL 311 2711 PD Brake discs, front Pre facelift, plain
DIXCEL 311 2711 SD Brake discs, front Pre facelift, slotted
DIXCEL 311 3168 HD Brake discs, front Facelift/CS/GrpA Rallye/RC, heat treated
DIXCEL 311 3168 HS Brake discs, front Facelift/CS/GrpA Rallye/RC, heat treated, slotted
DIXCEL 311 3168 PD Brake discs, front Facelift/CS/GrpA Rallye/RC, plain
DIXCEL 311 3168 SD Brake discs, front Facelift/CS/GrpA Rallye/RC, slotted
DIXCEL 315 3169 HD Brake discs, rear Facelift/CS/GrpA Rallye/RC, heat treated
DIXCEL 315 3169 HS Brake discs, rear Facelift/CS/GrpA Rallye/RC, heat treated, slotted
DIXCEL 315 3169 PD Brake discs, rear Facelift/CS/GrpA Rallye/RC, plain
DIXCEL 315 3169 SD Brake discs, rear Facelift/CS/GrpA Rallye/RC, slotted
DIXCEL 315 3179 HD Brake discs, rear Pre facelift, heat treated
DIXCEL 315 3179 HS Brake discs, rear Pre facelift, heat treated, slotted
DIXCEL 315 3179 PD Brake discs, rear Pre facelift, plain
DIXCEL 315 3179 SD Brake discs, rear Pre facelift, slotted
Jspeed 388002 Brake discs, front Super brake rotor, slotted (6)
Jspeed 388103 Brake discs, rear Super brake rotor, slotted (3)
Pit Road M Unknown Brake discs, front, Type-HSL Slotted
Pit Road M Unknown Brake disc, front, Type-NSL Slotted
Pit Road M Unknown Brake discs, rear, Type-HSL Slotted
Pit Road M Unknown Brake discs, rear, Type-NSL Slotted

Brake lines

Brand Part number Part Remarks
ACRE B1013 Brake lines, stainless steel braided Front/rear
APP TB016-ST Brake lines, stainless steel braided Front/rear
Jspeed 353100 Brake lines, stainless steel braided Front/rear
Pit Road M Unknown Brake lines, stainless steel braided Front/rear
Project μ BLT-023S Brake lines, stainless steel braided Front/rear, teflon coated
RG RGB-T016 Brake lines, stainless steel braided Front/rear, stainless steel fittings
RG RGB-T016T Brake lines, stainless steel braided Front/rear, steel fittings

Brake pads

Brand Part number Part Remarks
ACRE 168 Brake pads, rear
ACRE 217 Brake pads, front Facelift/CS/GrpA Rallye/RC
BLITZ 48281 Brake pads, front, MR-1 type Facelift/CS/GrpA Rallye/RC, 60~800 C, 0.38~0.45 μ
BLITZ 48321 Brake pads, rear, MR-1 type 60~800 C, 0.38~0.45 μ friction coefficient
DIXCEL 311 130 M Brake pads, front, M type Facelift/CS/GrpA Rallye/RC, Street sports, low dust
DIXCEL 311 130 Z Brake pads, front, Z type Facelift/CS/GrpA Rallye/RC, All-round performance
DIXCEL 311 144 M Brake pads, front, M type Pre facelift, Street sports, low dust
DIXCEL 311 144 Z Brake pads, front, Z type Pre facelift, All-round performance
DIXCEL 315 106 M Brake pads, rear, M type Street sports, low dust
DIXCEL 315 106 X Brake pads, rear, X type Off-road use
DIXCEL 315 106 Z Brake pads, rear, Z type All-round performance
ENDLESS EP168NS97 Brake pads, rear, NS97 Street use, 0~500 C, 0.37~0.43 μ friction coefficient
ENDLESS EP168SNP Brake pads, rear, SNP Street use, 0~400 C, 0.35~0.41 μ friction coefficient
ENDLESS EP168SSM Brake pads, rear, SuperStreet M-Sports Street~track use, 0~530 C, 0.30~0.40 μ friction
ENDLESS EP168SSY Brake pads, rear, SuperStreet Y-Sports Street/winding road use, 0~400 C, 0.38~0.48 μ
ENDLESS EP189SNP Brake pads, front, SNP Facelift/CS/GrpA Rallye/RC, street use, 0~400 C
ENDLESS EP189SSM Brake pads, front, SuperStreet M-Sports Facelift/CS/GrpA Rallye/RC, street~track use, 0~530 C
ENDLESS EP189SSY Brake pads, front, SuperStreet Y-Sports Facelift/CS/GrpA Rallye/RC, street/winding road use
ENDLESS EP221SNP Brake pads, front, SNP Pre facelift, street use, 0~400 C, 0.35~0.41 μ friction
ENDLESS EP221SSM Brake pads, front, SuperStreet M-Sports Pre facelift, street~track use, 0~530 C, 0.30~0.40 μ
ENDLESS EP221SSY Brake pads, front, SuperStreet Y-Sports Pre facelift, street/winding road use, 0~400 C
Jspeed 380800 Brake pads, front For hillclimb
Jspeed 380900 Brake pads, front For hillclimb
Jspeed 383800 Brake pads, rear For hillclimb
Jspeed 386800 Brake pads, rear For drifting
Jspeed 389900 Brake shoes, hand brake For drifting
Project μ F162 Bestop Brake pads, front Pre facelift, 0~350 C, 0.30~0.38 μ, like stock, street
Project μ F162 NS Brake pads, front Pre facelift, 0~400 C, 0.37~0.40 μ, street
Project μ F162 BooM-Wag Brake pads, front Pre facelift, 0~450 C, 0.36~0.43 μ, street
Project μ F162 B-Spec Brake pads, front Pre facelift, 0~500 C, 0.32~0.45 μ, street sport
Project μ F162 HC+ Brake pads, front Pre facelift, 0~800 C, 0.38~0.62 μ, street sport
Project μ F162 Comp-B/G Brake pads, front Pre facelift, 0~450 C, 0.38~0.62 μ, gymkhana
Project μ F162 LM700 Brake pads, front, Level Max Pre facelift, 50~700 C, 0.43~0.51 μ, track
Project μ F162 LM9001 Brake pads, front, Level Max Pre facelift, 100~900 C, 0.45~0.60 μ, track
Project μ F162 R777 Brake pads, front, Racing777 Pre facelift, 300~800 C, 0.40~0.55 μ, racing
Project μ F162 R999 Brake pads, front, Racing999 Pre facelift, 200~800 C, 0.42~0.59 μ, racing
Project μ F162 N1-Racing Brake pads, front Pre facelift, 100~800 C, 0.33~0.50 μ, racing
Project μ F165 Bestop Brake pads, front, like stock, street Facelift/CS/GrpA Rallye/RC, 0~350 C, 0.30~0.38 μ
Project μ F165 NS Brake pads, front, street Facelift/CS/GrpA Rallye/RC, 0~400 C, 0.37~0.40 μ
Project μ F165 BooM-Wag Brake pads, front, street Facelift/CS/GrpA Rallye/RC, 0~450 C, 0.36~0.43 μ
Project μ F165 B-Spec Brake pads, front, street sport Facelift/CS/GrpA Rallye/RC, 0~500 C, 0.32~0.45 μ
Project μ F165 HC+ Brake pads, front, street sport Facelift/CS/GrpA Rallye/RC, 0~800 C, 0.38~0.62 μ
Project μ F165 Comp-B/G Brake pads, front, Gymkhana Facelift/CS/GrpA Rallye/RC, 0~450 C, 0.38~0.62 μ
Project μ F165 LM700 Brake pads, front, Level Max, track Facelift/CS/GrpA Rallye/RC, 50~700 C, 0.43~0.51 μ
Project μ F165 LM9001 Brake pads, front, Level Max, track Facelift/CS/GrpA Rallye/RC, 100~900 C, 0.45~0.60 μ
Project μ F165 R777 Brake pads, front, Racing777 Facelift/CS/GrpA Rallye/RC, 300~800 C, 0.40~0.55 μ
Project μ F165 R999 Brake pads, front, Racing999 Facelift/CS/GrpA Rallye/RC, 200~800 C, 0.42~0.59 μ
Project μ F165 N1-Racing Brake pads, front Facelift/CS/GrpA Rallye/RC, 100~800 C, 0.33~0.50 μ
Project μ R162 Bestop Brake pads, rear 0~350 C, 0.30~0.38 μ, like stock, street
Project μ R162 NS Brake pads, rear 0~400 C, 0.37~0.40 μ, street
Project μ R162 BooM-Wag Brake pads, rear 0~450 C, 0.36~0.43 μ, street
Project μ R162 B-Spec Brake pads, rear 0~500 C, 0.32~0.45 μ, street sport
Project μ R162 HC+ Brake pads, rear 0~800 C, 0.38~0.62 μ, street sport
Project μ R162 Comp-B/G Brake pads, rear 0~450 C, 0.38~0.62 μ, gymkhana
Project μ R162 LM700 Brake pads, rear, Level Max 50~700 C, 0.43~0.51 μ, track
Project μ R162 LM9001 Brake pads, rear, Level Max 100~900 C, 0.45~0.60 μ, track
Project μ R162 R777 Brake pads, rear, Racing777 300~800 C, 0.40~0.55 μ, racing
Project μ R162 R999 Brake pads, rear, Racing999 200~800 C, 0.42~0.59 μ, racing
Project μ R162 N1-Racing Brake pads, rear 100~800 C, 0.33~0.50 μ, racing
SARD 68205A Brake pads, front, Type-A Facelift/CS/GrpA Rallye/RC, 100~600 C, street
SARD 68205C Brake pads, front, Type-C Facelift/CS/GrpA Rallye/RC, 300~800 C, track
SARD 68306A Brake pads, rear, Type-A 100~600 C, street
SARD 68306C Brake pads, rear, Type-C 300~800 C, track
TRD 04491-ST800 Brake pads, front, Black type Facelift/CS/GrpA Rallye/RC, 3410F performance model
TRD 04492-ST010 Brake pads, rear, Black type 9270S model, up to 500 C

Caliper piston springs

Brand Part number Part Remarks
Jspeed 301000 Caliper piston springs, front (2x) For 1 pot caliper (facelift/CS/GrpA Rallye/RC)
Jspeed 301100 Caliper piston springs, front (4x) For 2 pot caliper (pre facelift)

Master cylinder stopper

Brand Part number Part Remarks
Jspeed 389900 Master cylinder stopper For RHD car, or upside down mounting on LHD car




Chassis


Bushes

Brand Part number Part Remarks
TRD 48715-SW251 Bushes, rear sway bar
TRD 48818-AE061-17 Bushes, rear strut rods

Chassis braces

Brand Part number Part Remarks
Beatrush S81212-RTA Strut brace, rear ST205 brace - fits ST185 as well
C-ONE FT5361-ST200 Sports Rear tower bar type:S ST205 brace - fits ST185 as well
C-ONE FT5362-ST205 Sports Trunk bar type:S Space saver spare wheel still fits
CUSCO 152 475 A Lower arm bar, aluminium, type I 2 point
CUSCO 152 477 A Lower arm bar, aluminium, type II 4 point
CUSCO 152 510 A Strut brace, front, type ST Non CS/GrpA Rallye/RC
CUSCO 152 511 A Strut brace, rear, type AS
CUSCO 153 541 A Strut brace, rear, type OS ST205 brace - fits ST185 as well
Jspeed 500600 Door hinge braces Lower door hinge to chassis (wheel well)
Jspeed 530000 Lower arm bar 4 point
Jspeed 511100 Strut brace, front, triangular
Jspeed 511200 Strut brace, rear, triangular

Coilovers

Brand Part number Part Remarks
Jspeed 341700 Coilover kit, Type H Ride height adjustment, selectable spring rate
Pit Road M Unknown Coilover kit, Type-I Front 6~12 kg/mm, rear 4~10 kg/mm
Pit Road M Unknown Coilover kit, Type-II Front 7 kg/mm, rear 5 kg/mm
TEIN GST18-B1SS4 Coilover kit, SuperStreet Ride height and damping force adjustment

Diff. mount, rear

Brand Part number Part Remarks
C-ONE CB5229-ST205 Sports Diff. cushion
Jspeed 302100 Diff. mount, strengthened

Lowering springs

Brand Part number Part Remarks
Espelir EST-125 Lowering springs, front/rear Active super, front 35~40 mm/rear 25~30 mm drop
Jspeed 306600 Lowering springs, front/rear 20~30 mm drop

Roll cage

Brand Part number Part Remarks
CUSCO 152 261 C Roll cage, chromoly steel, D1 type 40 mm piping, 4 point, non sunroof
CUSCO 152 261 D Roll cage, chromoly steel, D1 type 40 mm piping, 5 point, non sunroof
CUSCO 152 261 E Roll cage, chromoly steel, D1 type 40 mm piping, 6 point, non sunroof
CUSCO 152 261 F Roll cage, chromoly steel, D1 type 40 mm piping, 7 point, non sunroof
CUSCO 152 261 G Roll cage, chromoly steel, D1 type 40 mm piping, 8 point, non sunroof
CUSCO 152 265 E Roll cage, chromoly steel, D1 type 40 mm piping, 6 point, through dashboard, non sunroof
CUSCO 152 265 F Roll cage, chromoly steel, D1 type 40 mm piping, 7 point, through dashboard, non sunroof
CUSCO 152 265 G Roll cage, chromoly steel, D1 type 40 mm piping, 8 point, through dashboard, non sunroof
CUSCO 152 270 C20 Roll cage, steel, Safety 21 40 mm piping, 4 point, non sunroof
CUSCO 152 270 D20 Roll cage, steel, Safety 21 40 mm piping, 5 point, non sunroof
CUSCO 152 270 E20 Roll cage, steel, Safety 21 40 mm piping, 6 point, non sunroof
CUSCO 152 270 F20 Roll cage, steel, Safety 21 40 mm piping, 7 point, non sunroof
CUSCO 152 270 G20 Roll cage, steel, Safety 21 40 mm piping, 8 point, non sunroof
CUSCO 152 290 E20 Roll cage, steel, Safety 21 40 mm piping, 6 point, through dashboard, non sunroof
CUSCO 152 290 F20 Roll cage, steel, Safety 21 40 mm piping, 7 point, through dashboard, non sunroof
CUSCO 152 290 G20 Roll cage, steel, Safety 21 40 mm piping, 8 point, through dashboard, non sunroof
Saito RollCage Unknown Roll cage, custom Custom specification

Shock absorbers

Brand Part number Part Remarks
KYB NSC4091 Shock absorbers, front New SR Special, stock replacement
KYB NST5048RL Shock absorbers, rear New SR Special, stock replacement

Sway bar

Brand Part number Part Remarks
C-ONE CS4883-ST205 Sports Rear stabilizer bar ST205 bar, fits ST185 as well

Top mounts, shock absorber

Brand Part number Part Remarks
C-ONE CS4860-ST180 Top mount, pillow ball, front Camber adjustment
C-ONE CS4807-ST200 Top mount, pillow ball, rear
CUSCO 151 410 A Top mount, pillow ball, front Camber adjustment
CUSCO 152 421 A Top mount, pillow ball, rear
Jspeed 371200 Top mount, pillow ball, front Camber adjustment, for 341700 coilover kit
Jspeed 372700 Top mount, pillow ball, front Camber adjustment

Wheel spacers

Brand Part number Part Remarks
Jspeed 306600 Wheel spacers, Wide track kit (2x) 25 mm per side, hub centric




Engine


Air filter (kit)

Brand Part number Part Remarks
A'PEXi 503-T102 Air filter, panel, Power Intake Filter
A'PEXi 507-T007 Air filter kit, Power Intake SW20 kit, fits ST185 with battery relocation as well
BLITZ 59500 Air filter, panel SUS filter LM ST-31B
HKS 70019-AT019 Air filter kit, Super Power Flow Reloaded 200x70 mm, non CS/GrpA Rallye/RC
Jspeed 221100 Air filter kit, Super Power Flow HKS based, CS/GrpA Rallye/RC only
Jspeed 222000 Suction pipe kit Battery relocation required
Power Enterprise AI-T312 Air filter kit, Air Impulse Non CS/GrpA Rallye/RC
SARD 63004 Air filter, panel, EX-T05 EX-ion Filter

Bearings

Brand Part number Part Remarks
Power Enterprise 1101-MT211 Bearings, connecting rod (8x) Type 1, 1.5 mm -0.012~-0.016 mm*
Power Enterprise 1101-MT212 Bearings, connecting rod (8x) Type 2, 1.5 mm -0.008~-0.012 mm*
Power Enterprise 1101-MT213 Bearings, connecting rod (8x) Type 3, 1.5 mm -0.004~-0.008 mm*
Power Enterprise 1101-MT214 Bearings, connecting rod (8x) Type 4, 1.5 mm 0~-0.004 mm*
Power Enterprise 1101-MT215 Bearings, connecting rod (8x) Type 5, 1.5 mm +0.004~0 mm*
Power Enterprise 1101-MT216 Bearings, connecting rod (8x) Type 6, 1.5 mm +0.008~+0.004 mm*
Power Enterprise 1102-MT211 Bearings, crank shaft (10x) Type 1, 2.0 mm +0.001~-0.003 mm*
Power Enterprise 1102-MT212 Bearings, crank shaft (10x) Type 2, 2.0 mm +0.005~+0.001 mm*
Power Enterprise 1102-MT213 Bearings, crank shaft (10x) Type 3, 2.0 mm +0.009~+0.005 mm*
Power Enterprise 1102-MT214 Bearings, crank shaft (10x) Type 4, 2.0 mm +0.013~+0.009 mm*
Power Enterprise 1102-MT215 Bearings, crank shaft (10x) Type 5, 2.0 mm +0.017~+0.013 mm*
Power Enterprise 1102-MT216 Bearings, crank shaft (10x) Type 6, 2.0 mm +0.021~+0.017 mm*
Power Enterprise 1103-MT211 Bearings, crank shaft (10x) Type 1, 2.0 mm -0.004~-0.008 mm*
Power Enterprise 1103-MT212 Bearings, crank shaft (10x) Type 2, 2.0 mm 0~-0.004 mm*
Power Enterprise 1103-MT213 Bearings, crank shaft (10x) Type 3, 2.0 mm +0.004~0 mm*
Power Enterprise 1103-MT214 Bearings, crank shaft (10x) Type 4, 2.0 mm +0.008~+0.004 mm*
Power Enterprise 1103-MT215 Bearings, crank shaft (10x) Type 5, 2.0 mm +0.012~+0.008 mm*
Power Enterprise 1103-MT216 Bearings, crank shaft (10x) Type 6, 2.0 mm +0.016~+0.012 mm*

* Check male tolerances at Power Enterprise website.

Cam gears

Brand Part number Part Remarks
HKS 22004-AT002 Cam gear, duralumin, in. or ex. Nickel plated gear teeth
JUN 1006M-T003 Cam gear, intake or exhaust -4~+4

Cam shaft

Brand Part number Part Remarks
HKS 2202-RT063 Cam shaft, intake, 264 duration 9.00 mm lift
HKS 2202-RT064 Cam shaft, exhaust, 264 duration 8.95 mm lift
HKS 2202-RT065 Cam shaft, intake, 272 duration 9.20 mm lift
HKS 2202-RT066 Cam shaft, exhaust, 272 duration 9.15 mm lift
JUN 1004M-T001 Cam shaft, intake, 256 duration High lift, 9.00 mm lift, 0.20 mm valve clearance (cold)
JUN 1004M-T002 Cam shaft, intake, 264 duration High lift, 9.00 mm lift, 0.20 mm valve clearance (cold)
JUN 1004M-T003 Cam shaft, intake, 272 duration High lift, 9.30 mm lift, 0.20 mm valve clearance (cold)
JUN 1004M-T101 Cam shaft, exhaust, 256 duration High lift, 9.00 mm lift, 0.33 mm valve clearance (cold)
JUN 1004M-T102 Cam shaft, exhaust, 264 duration High lift, 9.00 mm lift, 0.33 mm valve clearance (cold)
JUN 1004M-T103 Cam shaft, exhaust, 272 duration High lift, 9.30 mm lift, 0.33 mm valve clearance (cold)

Cam shaft kit

Brand Part number Part Remarks
JUN 1033M-T004 Cam shaft kit, selectable duration Stage 1, including valve springs
JUN 1033M-T005 Cam shaft kit, selectable duration Stage 2, including valve springs and Type 1 retainers
JUN 1033M-T007 Cam shaft kit, selectable duration Stage 2R, including valve springs and Type 2 retainers
JUN 1033M-T702 Cam gear, optional part for JUN kit Reduced price when bought with cam shaft kit

Connecting rods

Brand Part number Part Remarks
HKS 2304-RT005 Connecting rods, forged, H beam 22 mm pin
JUN 1002M-T002 Connecting rods, I-beam SCM440, 22 mm pin, 51 mm big end, 578 gr.
JUN 1002M-T002 Connecting rods, I-beam For 2.2L kit, 22 mm pin, 51 mm big end, 568 gr.

Crank shaft

Brand Part number Part Remarks
HKS 2306-RT009 Crankshaft, forged, 90 mm stroke For 2104-RT035 stroker kit

Crank shaft studs

Brand Part number Part Remarks
JUN 1025M-T003 Crank shaft studs, caps to block Made by ARP

Crank shaft pulley

Brand Part number Part Remarks
Beatrush S91211PA Crank shaft pulley, aluminium 720 gr. (stock: 2060 gr.)
C-ONE FE1347-ST200 Crank shaft pulley, aluminium 640 gr. (stock: 2080 gr.)

ECU

Brand Part number Part Remarks
Jspeed 125000 ECU 'Super computer' Core exchange stock ECU
Jspeed 127000 ECU 'Super computer' Core exchange stock ECU, with misfiring system
Pit Road M Unknown ECU, M-SPL CPU

ECU coupler

Brand Part number Part Remarks
FIELD CN-3 ECU coupler, One Touch Harness extention, 15 cm
K's Meter Works XH 012 ECU coupler Harness extention

Electronics

Brand Part number Part Remarks
HKS 4103-RT003 Turbo timer harness TT-3, for HKS turbo timer
HKS 4399-ST002 Twin power harness T-2, for HKS Twin Power ignition amplifier
HKS 4501-RA002 Fuel Cut Defencer (FCD)
ULTRA 4761-32 Turbo timer harness For ULTRA turbo timer
ULTRA 9521-10 MDI harness For ULTRA MDI ignition amplifier

Exhaust

Brand Part number Part Remarks
BLITZ 23300 Exhaust, stainless steel muffler Realize TT, cat-back, 60 mm piping, 100 mm tip
BLITZ 25300 Exhaust, stainless steel Realize TT-R, cat-back, 60 mm piping, 100 mm tip
BLITZ 66737 Exhaust, stainless steel Nr-Spec V, cat-back, 70 mm piping, 105 mm tip
BLITZ 68120 Exhaust, stainless steel Nr-Spec RX, cat-back, 70 mm piping, JASMA approved
BLITZ MT2060 Exhaust, stainless steel Nr-Spec S, axle-back, 70 mm piping, JASMA approved
BLITZ MT3070 Exhaust, stainless steel Nr-Spec R, cat-back, 70 mm piping, 114.3 mm tip
HKS 31019-AT009 Exhaust, SUS304 stainless steel Silent Hi-Power, cat-back, 3" piping, JASMA approved
HPI HPTOF-SW20 Exhaust, downpipe SW20 downpipe, fits ST185 as well, 3" piping
Jspeed 223200 Exhaust, stainless steel, 100 mm tip J-Power muffler, cat-back, 1 mm piping thickness
Jspeed 223200 Exhaust, mid-pipe, stainless steel 60 mm piping
Kakimoto Racing TS323 Exhaust, stainless steel Cat-back, 70 mm piping, 115 mm tip, JASMA approved
SARD 60402 Exhaust, stainless steel Arouse MIG, cat-back, 60 mm piping, 100 mm tip
SARD 89084 Catalyzer, replaces stock lower half ST205 Sports cat, fits ST185 as well, 3" outlet
SARD 89085 Catalyzer, replaces stock downpipe ST205 Sports cat, fits ST185 as well, 3" inlet and outlet

Exhaust manifold

Brand Part number Part Remarks
Brash Boy Unknown Exhaust manifold, stainless steel For stock turbo, 45 mm piping

Ground wire kit

Brand Part number Part Remarks
SplitFire GWT-071 Ground wire kit

Head gasket

Brand Part number Part Remarks
HKS 2301-RT034 Head gasket, metal, 1.0 mm Stopper type, 87.5 mm bore, 8.80 C/R
HKS 2301-RT035 Head gasket, metal, 1.6 mm Stopper type, 87.5 mm bore, 8.38 C/R
Pit Road M Unknown Head gasket, metal, 0.8 mm
Pit Road M Unknown Head gasket, metal, 1.0 mm
Pit Road M Unknown Head gasket, metal, 1.2 mm
Pit Road M Unknown Head gasket, metal, 1.5 mm
Pit Road M Unknown Head gasket, metal, 1.8 mm
Power Enterprise Unknown Head gasket, metal, 1.5 mm Grommet type, 87.0 mm bore
TRD 11115-SW201 Head gasket, metal, 0.8 mm C type

Head studs

Brand Part number Part Remarks
JUN 1027M-T002 Head studs Made by ARP

Intercooler kit

Brand Part number Part Remarks
Brash Boy Unknown Intercooler kit, TRUST GT-R core based 2 row core, 600x284x76 mm, including piping
Jspeed 227000 Intercooler kit CS/GrpA Rallye/RC only

Oil drain plug

Brand Part number Part Remarks
Kics Project Unknown Oil drain plug, Magnet drain bolt
K's Meter Works MPD-02 Oil drain plug, MAG Power Magnetic
SARD 19338 Oil drain plug, SDM-04, Sports MAG+ Dren plug, magnetic

Oil filter

Brand Part number Part Remarks
BLITZ 18700 Oil filter, paper, B-9271 model 65 mm OD, 65 mm tall, 20% surface increase
Power Enterprise OFII-03A Oil filter, paper, Mag power II Magnetic (3000 gauss)
SARD 63192 Oil filter, paper, SMF02, Sports MAG+ 65 mm OD, 87 mm tall, high flow, magnetic
TRD 90915-SP010 Oil filter, paper High flow
TRUST 13901101 Oil filter, double layer paper 65 mm OD, 75 mm tall
TRUST 13901103 Oil filter, double layer paper 65 mm OD, 90 mm tall

Pistons

Brand Part number Part Remarks
ATS TSS06080809 Pistons, forged, 86.5 mm Made by Mahle, 22 mm pin, -4.0 cc, 9.00 C/R, 323 gr.
HKS 2103-RT029 Pistons, forged, 87.0 mm 22 mm pin, 2045 cc, 8.50 C/R with 1.2 mm HG
HKS 2103-RT032 Pistons, forged, 87.0 mm 22 mm pin, for 2104-RT035 stroker kit
JUN 1001M-T003 Pistons, forged, 87.0 mm, Super Made by Cosworth, 22 mm pin, -12.9 cc, 458 gr.
JUN 1001W-T031 Pistons, forged, 86.0 mm, Excellent Made by Wssner, 22 mm pin, -6.0 cc
JUN 1001W-T032 Pistons, forged, 86.5 mm, Excellent Made by Wssner, 22 mm pin, -6.0 cc
JUN 1001W-T033 Pistons, forged, 87.0 mm, Excellent Made by Wssner, 22 mm pin, -6.0 cc
TODA Racing 13020-3SG-T00 Pistons, forged, 87.0 mm 2045 cc, -7.5 cc, 8.30 C/R with 1.5 mm HG

Plug wires

Brand Part number Part Remarks
NGK 47T Plug wires, Power Cable Facelift/CS/Grpa A Rallye/RC, 0.9 kΩ/m
NGK TX14 Plug wires Pre facelift, 8 kΩ/m
NGK TX69 Plug wires Facelift/CS/Grpa A Rallye/RC, 8 kΩ/m
SplitFire TC-T35 Plug wires, Twin core Pre facelift
SplitFire TC-T64 Plug wires, Twin core Facelift/CS/Grpa A Rallye/RC
ULTRA 2144-10 Plug wires, Silicone Power Pre facelift
ULTRA 3146-10 Plug wires, Silicone Power Facelift/CS/Grpa A Rallye/RC
ULTRA 3146-40 Plug wires, Blue Point Silicone Power Facelift/CS/Grpa A Rallye/RC, 0.5 kΩ/m

Radiator

Brand Part number Part Remarks
Brash Boy Unknown Radiator, aluminium, 3 row
KOYO PA010726 Radiator, copper, 2 row Type-S Plastic endtanks, 27 mm core
Pit Road M Unknown Radiator, aluminium, 3 row
Pit Road M Unknown Radiator, copper, 3 row
RG RKA010726 Radiator, copper, 3 row Power radiator, 41 mm core
RG RKL010726 Radiator, aluminium, 2 row Power radiator, 53 mm core
Signal Auto Unknown Radiator, aluminium, 3 row
Signal Auto Unknown Radiator, copper, 2 row
Signal Auto Unknown Radiator, copper, 3 row

Radiator cap

Brand Part number Part Remarks
A'PEXi 591-A001 Radiator cap, S-type 130 kPa, intercooler, CS/GrpA Rallye/RC only
A'PEXi 591-A002 Radiator cap, N-type 130 kPa
ARC AMC001 Radiator cap, A-type 127 kPa, intercooler, CS/GrpA Rallye/RC only
ARC AMC003 Radiator cap, B-type 127 kPa
ARC AMC004 Radiator cap, A-type 108 kPa, intercooler, CS/GrpA Rallye/RC only
Billion BHR-01A Radiator cap, A-type 127 kPa, intercooler, CS/GrpA Rallye/RC only
Billion BHR-02B Radiator cap, B-type 127 kPa
Carbing 222 000 0 Radiator cap, A-type 127 kPa, intercooler, CS/GrpA Rallye/RC only
Carbing 222 001 0 Radiator cap, B-type 127 kPa
C-ONE FE1640- SP001 Radiator cap, N-type
C-ONE FE1640- SP010 Radiator cap, S-type Intercooler, CS/GrpA Rallye/RC only
HKS 15009-AK003 Radiator cap, N-type 108 kPa
HKS 15009-AK004 Radiator cap, S-type 108 kPa, intercooler, CS/GrpA Rallye/RC only
Power Enterprise Unknown Radiator cap, N-type 130 kPa
Power Enterprise Unknown Radiator cap, T-type 130 kPa, intercooler, CS/GrpA Rallye/RC only
SARD 61005 Radiator cap, S-type, SHP05 130 kPa, intercooler, CS/GrpA Rallye/RC only
SARD 61006 Radiator cap, N-type, SHP06 130 kPa
SARD 61007 Radiator cap, S-type, SHP07 150 kPa, intercooler, CS/GrpA Rallye/RC only
TRD 16401-SP002 Radiator cap, S-type 127 kPa, intercooler, CS/GrpA Rallye/RC only
TRD 16401-SP020 Radiator cap, S-type 147 kPa, intercooler, CS/GrpA Rallye/RC only
TRD 16401-SP030 Radiator cap, N-type 127 kPa
TRUST 13901000 Radiator cap, S-type 127 kPa, intercooler, CS/GrpA Rallye/RC only
TRUST 13901001 Radiator cap, N-type 127 kPa

Stroker kit

Brand Part number Part Remarks
HKS 2104-RT035 Stroker kit, 2.2 L (2140 cc) 87 mm forged pistons, forged billet crank (90 mm stroke)
JUN 1029M-T001 Stroker kit, 2.2 L (2188 cc), Custom 87 mm forged Cosworth pistons, forged billet crank (18 kg, 92 mm stroke), 8.30 C/R with 1.2 mm HG
JUN 1029M-T003 Stroker kit, 2.2 L (2188 cc) 87 mm forged Cosworth pistons, I-beam connecting rods, carved crank (17 kg, 92 mm stroke)
JUN 1029M-T004 Stroker kit, 2.2 L (2188 cc), Custom II 87 mm forged Cosworth pistons, carved crank (17 kg, 92 mm stroke), 8.30 C/R with 1.2 mm HG

Thermostat

Brand Part number Part Remarks
ARC AFC01 Thermostat, 68 C
Billion BST-06 Thermostat, 65 C, Super thermo
Billion BST-W06 Thermostat, 71 C, Super thermo
HKT GST-07 Thermostat, 71 C, GT Spec. thermo
SARD 19402 Thermostat, 68 C, SST02
TRD 16340-SP010 Thermostat, 71 C

Timing belt

Brand Part number Part Remarks
HKS 24999-AT007 Timing belt, fine tune Size 178Y25.4
Power Enterprise BT221 Timing belt, Super kevlar II Nylon/kevlar, anti growth
TRUST 13514503 Timing belt Nylon/aramide

Turbo kit

Brand Part number Part Remarks
Brash Boy Unknown Turbo kit, T517Z/T618Z TRUST based Including elbow, connects to stock cat.
TRUST 11510012 Turbine kit, TD05H 18G-8.0cm2 P765 SW20 kit, manifold adapter, internal wastegate, 236 ps @ 83.4 kPa
TRUST 11510013 Turbine kit, TD06S L2 20G-8.0cm2 SW20 kit, stainless steel tubular manifold, 42.7 mm piping, R08 external wastegate, 322 ps @ 117.8 kPa
TRUST 11510015 Turbine kit, T67 25G-8.0cm2 SW20 kit, stainless steel tubular manifold, 42.7 mm piping, R08 external wastegate, 380 ps @ 117.8 kPa

Valve guides

Brand Part number Part Remarks
JUN 1008M-T002 Valve guides Phosphorus bronze

Valve retainers

Brand Part number Part Remarks
JUN 1005M-T004 Valve retainers, Type 1 Titanium, 7 gr.
JUN 1005M-T204 Valve retainers, Type 2 Titanium, 7 gr., improved wear resistance

Valve springs

Brand Part number Part Remarks
HKS 2201-RT014 Valve springs For HKS cam shafts
JUN 1009M-T001 Valve springs, 10 mm cam lift max. 3.9 mm, 34.5~24.5 mm length, 30.0~72.8 kg load
Pit Road M Unknown Valve springs




Exterior


Bonnet

Brand Part number Part Remarks
CUSCO 152 810 A Bonnet, FRP Non CS/GrpA Rallye/RC
Pit Road M Unknown Bonnet, carbon 5.8 kg, CS/GrpA Rallye/RC
Pit Road M Unknown Bonnet, FRP 7.3 kg, CS/GrpA Rallye/RC

Mirrors

Brand Part number Part Remarks
Autosport Iwase Unknown Mirrors, carbon, works WRC

Mud flaps

Brand Part number Part Remarks
C-ONE FB7660-ST185 Mud flap set, urethane Red, aluminium brackets




Interior


Car mats

Brand Part number Part Remarks
FET KARO 1064 Car mats, front/rear (4x) RHD only, various colours

Dashboard

Brand Part number Part Remarks
SARD 67209 STACK Meter panel, carbon

Speedometer

Brand Part number Part Remarks
K's Meter Works Unknown Speedometer, 270 km/h Core exchange stock gauge cluster

Steering wheel boss

Brand Part number Part Remarks
HKB Sports OT-48 Steering wheel boss
Works Bell 522 Steering wheel boss 40 mm




Transmission


Clutch

Brand Part number Part Remarks
ATS CT23132-11 Single plate clutch, carbon, Pro spec. 1100 kg pressure plate, including flywheel
ATS CT23132-14 Single plate clutch, carbon, Pro spec. 1350 kg pressure plate, including flywheel
ATS CT23230-11 Twin plate clutch, carbon, standard 1100 kg pressure plate, including flywheel
ATS CT23230-14 Twin plate clutch, carbon, standard 1350 kg pressure plate, including flywheel
ATS CT23235-11 Twin plate clutch, carbon, Type R 1100 kg pressure plate, including flywheel
ATS CT23235-14 Twin plate clutch, carbon, Type R 1350 kg pressure plate, including flywheel
ATS CT23236-11 Twin plate clutch, carbon, soft type 1100 kg pressure plate, including flywheel
ATS CT23236-14 Twin plate clutch, carbon, soft type 1350 kg pressure plate, including flywheel
CUSCO 00C 022 C302T Clutch disc, metal 240 mm
CUSCO 00C 022 B252 Clutch cover, reinforced 950 kg pressure plate, 240 mm
CUSCO 00C 022 SC225 Clutch cover, assembly Replacement part for 137 022 SP clutch set
CUSCO 00C 022 SP225 Pressure plate 1280 kg, replacement part for 137 022 SP clutch set
CUSCO 00C 022 SD3S Clutch disc Replacement part for 137 022 SP clutch set
CUSCO 137 022 SBG Throw-out bearing Replacement part for 137 022 SP clutch set
CUSCO 137 022 SP Single plate clutch 1280 kg pressure plate, 225 mm, including flywheel, up to ~400 ps
EXEDY BRG609 Throw-out bearing Replacement part for TK05H906/TK05T906 clutch set
EXEDY TC05T Pressure plate 950 kg, replacement part for TK05H906/TK05T906 clutch set
EXEDY TD05H Clutch disc, organic Replacement part for TK05H906 clutch set
EXEDY TD05T Clutch disc, metal Replacement part for TK05T906 clutch set
EXEDY TH02SBMC1 Single plate clutch, Carbon-R 1325 kg pressure plate, 225 mm, including flywheel
EXEDY TH02SD Single plate clutch, Hyper 1200 kg pressure plate, 250 mm, including flywheel
EXEDY TK05H906 Single plate clutch, organic
EXEDY TK05T906 Single plate clutch, metal
EXEDY TM012SBMC1 Twin plate clutch, Carbon-R 1200 kg pressure plate, 202 mm, including flywheel
EXEDY TM012SR Twin plate clutch, Hyper 1000 kg pressure plate, 200 mm, including flywheel
HKS 26004-AT001 Twin plate clutch, GD Max Push type, including 6.4 kg flywheel
HKS 2604-RT003 Twin plate clutch, GD Pro Push type, including 6.4 kg flywheel, up to ~980 Nm/~600 ps
JUN 2511M-T009 Single plate clutch, metal 950 kg pressure plate, including flywheel
JUN 2512M-T009 Single plate clutch, metal, 3 puck 950 kg pressure plate, including flywheel
JUN 2521M-T009 Single plate clutch, metal 950 kg pressure plate, including Ultralight flywheel
JUN 2522M-T009 Single plate clutch, metal, 3 puck 950 kg pressure plate, including Ultralight flywheel
Ogura Clutch 400L-HP-TT0303 Single plate clutch, ORC400 Light HP 17~19 kg pedal pressure, up to ~490 Nm/~420 ps
Ogura Clutch 400L-TT0303 Single plate clutch, ORC400 Light STD 12~15 kg pedal pressure, up to ~330 Nm/~330 ps
Ogura Clutch ORC-409D-03T Single plate clutch, Metal series Including flywheel, up to ~420 Nm
OS Giken Unknown Single plate clutch, SS-S type Pressed cover, 225 mm, including flywheel
OS Giken Unknown Twin plate clutch, R2CD type 1090 kg pressure plate, 215 mm, including flywheel
OS Giken Unknown Twin plate clutch, STR2C type Aluminium cover, 25% lighter pedal, including flywheel
OS Giken Unknown Twin plate clutch, TS2B type 1000 kg pressure plate, 204 mm, including flywheel
TODA Racing 22200-3SG-T0M Clutch disc, metal
TODA Racing 22200-3SG-T1N Clutch disc, Sports facing
TODA Racing 22300-3SG-T00 Clutch cover, reinforced
TRD 31210-SW252 Clutch cover 950 kg pressure plate, 236 mm
TRD 31250-SW252 Clutch disc, Sports facing

Clutch line

Brand Part number Part Remarks
Jspeed 352100 Clutch line, stainless steel braided

Differential, rear

Brand Part number Part Remarks
CUSCO LSD 133 A Differential, limited slip, Type MZ 1 & 2 Way model - 1 Way, track oriented
CUSCO LSD 133 A2 Differential, limited slip, Type MZ 1 & 2 Way model - 2 Way, track oriented
CUSCO LSD 133 F Differential, limited slip, Type RS 1 & 2 Way model - 1 Way, street oriented
CUSCO LSD 133 F2 Differential, limited slip, Type RS 1 & 2 Way model - 2 Way, street oriented
CUSCO LSD 133 K15 Differential, limited slip, Type MZ 1.5 & 2 Way model - 1.5 Way, track oriented
CUSCO LSD 133 K2 Differential, limited slip, Type MZ 1.5 & 2 Way model - 2 Way, track oriented
CUSCO LSD 133 L15 Differential, limited slip, Type RS 1.5 & 2 Way model - 1.5 Way, street oriented
CUSCO LSD 133 L2 Differential, limited slip, Type RS 1.5 & 2 Way model - 2 Way, street oriented

Flywheel

Brand Part number Part Remarks
C-ONE FF1340-ST210 Flywheel, chromoly steel 4.8 kg
C-ONE FF1340-ST21R Flywheel, chromoly steel, Type R 4.4 kg
CUSCO 00C 022 SFSW Flywheel Replacement part for 137 022 SP clutch kit
CUSCO 137 023 T Flywheel, chromoly steel 4.5 kg
JUN 2001M-T012 Flywheel, chromoly steel 4.7 kg, forged
JUN 2010M-T012 Flywheel, chromoly steel, Ultralight 4.6 kg, forged
Kameari Unknown Flywheel, chromoly steel, STD 4.6 kg
Kameari Unknown Flywheel, chromoly steel, Type R 3.6 kg
TODA Racing 22100-3SG-T00 Flywheel, chromoly steel, Ultra light 4.5 kg

Gear set

Brand Part number Part Remarks
Brash Boy Unknown Cross mission 1: 3.230, 2: 2.142, 3: 1.518, 4: 0.972
C-ONE FG3303-ST210 Sports Cross mission 1: 3.231, 2: 2.235, 3: 1.667, 4: 1.250, 5: 0.929
KAAZ MCT2050 Sports Cross mission 1: 3.231, 2: 2.235, 3: 1.667, 4: 1.250, 5: 0.964



Related links

Modifications

Top
